DIMLUX XTREME
SERIES LED

Light Output Total
(PPF 350-800nm)

3142 μmol/s

INTRODUCING THE MOST POWERFUL AND SMART LED
GROW LIGHT ON THE MARKET! THE DIMLUX XTREME SERIES LED.

Dimlux Expert MKII with Removable Ultra optics reflector

MAXI CONTROLLER OPTIMALE CONTROLE MAXIMALE PRESTATIES

INTRODUCING THE MOST
POWERFUL AND SMART LED
GROW LIGHT ON THE MARKET!
THE DIMLUX XTREME SERIES LED.

12 Years ago, Dimlux introduced the first ever groundbreaking remote controlled HPS ballast in combination with the Maxi Controller; The Dimlux Xtreme Series. Today, Dimlux introduces the smartest, most efficient and most powerful grow light on the market, the Dimlux Xtreme Series LED! Again we are in the forefront of innovation.

INTRODUCING THE MOST
POWERFUL AND SMART LED
GROW LIGHT ON THE MARKET!
THE DIMLUX XTREME SERIES LED.

12 Years ago, Dimlux introduced the first ever groundbreaking remote controlled HPS ballast in combination with the Maxi Controller; The Dimlux Xtreme Series. Today, Dimlux introduces the smartest, most efficient and most powerful grow light on the market, the Dimlux Xtreme Series 750W LED!

OUR PRODUCTRANGE

XTREME SERIES LED

500W, 750W and 1000W

Expert SERIES MKII

600W and 1000W

HOOGST MOGELIJKE EFFICIËNTIE

400-600W and 600W EL UHF

maxi controller

EVO 1.2 and EVO 1.4 DATALOG

for over 15 years we have been creating the most efficient lighting solutions

Being a global market leader in assimilation lighting for the professional horticulture and indoor growing industries. Since we started producting fixtures, a strong emphasis has been placed on innovation and quality.

Dimlux has all the knowledge it needs in house to work with you to design the best possible lighting installations. Our well-equipped laboratory for developing new and improving existing products, along with our own production, ensures the constant high quality of our fixtures.

“We observe our competition but always lead by example and innovation”


Ronald van de Oudeweetering
– Founder & Director of innovations
Dimlux, Netherlands

GOING WHERE NO BULB
HAS EVER GONE BEFORE!

Developed with one goal in mind, to be the most efficient lamp ever made

Dimlux Xtreme Output HPS 400V 600/750W EL



System Light Output PAR (PPF 400-700nm)

1536μmol/s @750W



System Light Output PAR Total (PPF 350-800nm)

1690μmol/s @750W



System Photon Efficacy PAR (PPE 400-700nm)

2,04μmol/J @700-750W



System Photon Efficacy PAR Total (PPE 350-800nm)

2,24μmol/J @700-750W



Dimlux Xtreme Output HPS 400V 1000/1250W DE EL



System Light Output PAR (PPF 400-700nm)

2725μmol/s @1250W



System Light Output PAR Total (PPF 350-800nm)

2997μmol/s @1250W



System Photon Efficacy PAR (PPE 400-700nm)

2,18μmol/J @1150-1250W



System Photon Efficacy PAR Total (PPE 350-800nm)

2,39μmol/J @1150-1250W



Dimlux Xtreme Output California Spec HPS 400V 1000/1250W DE EL

System Light Output PAR (PPF 400-700nm)

2780μmol/s @1250W



System Light Output PAR Total (PPF 350-800nm)

3070μmol/s @1250W



System Photon Efficacy PAR (PPE 400-700nm)

2,23μmol/J @1150-1250W



System Photon Efficacy PAR Total (PPE 350-800nm)

2,46μmol/J @1150-1250W



The only fixture in the world to meet the Horticultural Lighting Minimum Efficacy 2022 (2023) California Energy Code

The new 1000/1250W MKII DXO CA fixture, fitted with our new DXO CA Spec lamp, is the only combination in the world to achieve a System Efficiency (PPE) greater than 2.1 µmol/J, an unprecedented feat that was once thought impossible . Most competing brands do not reach 1.8 µmol/J, and only a few reach 1.9 µmol/J.

DXO ca 1000/1250W USPs

  • Optimized red and orange spectrum and high PAR (Photosynthetic Active Radiation) to stimulate flower growth and improve fruiting,
  • The only lamp optimized for High Frequency electronic ballasts with 1000-1250W boost,
  • Works with any high frequency electronic 1000W fixture or ballast,
  • Top efficacy at 1150-1250W, and outperforming any other make and model even at 1000W,



  • Dimming range 600-1250W,
  • Only lamp that reaches over 2.2μmol/J and even more than 2.4μmol/J in the PAR Total range (350-800nm),
  • Highest share of Far-Red in the market, which has, together with red, has an equal or even greater effect on photosynthesis. The ratio R:FR = 6:1 (sunlight = 1:1, LED = between 20:1 and 10:1)

AN ULTIMATE RANGE OF REFLECTORS TO MEET EVERYONE’S NEEDS



The main goal in designing the Ultra Optics Reflector was to achieve the highest efficiency (light output) possible. It’s designed according to the SBCS (Single Bounce Clear Sight) principle which

Ultra Optics Hybrid 98%

The Hybrid reflector ensures a deep penetration into the plants, while having a larger overlap with other fixtures for better uniformity. The area it illuminates has an aspect ratio of 1.3:1. This reflector is the ideal choice for many scenarios because it combines the best qualities of the Deep and Wide reflectors.

Ultra Optics Wide 98%

The Wide reflector illuminates a much wider area, which allows for a very short distance between the plants and the reflector. Because of the wider spread, the distance between the crop and reflector for the 1000W fixture is about the same as a regular 600W system. The area it illuminates has an aspect ratio of 2:1, a rectangle.

Ultra Optics Deep 98%

The Deep reflector allows the light to penetrate very deep into the canopy. Because the Deep reflector directs more light downwards and less to the sides, losses due to walls and walking paths are minimized. The area it illuminates has an aspect ratio of 1:1, square.
