DIMLUX PRO

PROFESSIONAL HORTICULTURE LIGHTING SOLUTION

System PPF@1150W:

2339 μmol/s

Removable Ultra optics reflector

4 digit display with boost function

PROFESSIONAL HORTICULTURE LIGHTING SOLUTIONS

Dimlux develops and manufactures tailored lighting solutions urban farming and small scale production and large scale horticulture. With decades of experience our engineers have combined the newest techniques and innovations to create the most advanced complete lighting system on the market on the market today.

PROFESSIONAL HORTICULTURE LIGHTING SOLUTIONS

Dimlux develops and manufactures tailored lighting solutions urban farming and small scale production and large scale horticulture. With decades of experience our engineers have combined the newest techniques and innovations to create the most advanced complete lighting system on the market on the market today.

DIMLUX PRO 1000W

277-347V SMART EXCEEDCONN

  • 277V
  • EU + CAN Market
  • Efficient light distribution
  • System PPF@1000W: 2016μmol/s
  • System PPF@1150W: 2339μmol/s

DIMLUX PRO 1000W

208-240V SMART IEC

  • 230V
  • EU + UK + US Market
  • Efficient light distribution
  • System PPF@1000W: 2016μmol/s
  • System PPF@1150W: 2339μmol/

DIMLUX PRO 1000W

347-400V SMART EXCEEDCONN

  • 400V
  • EU + UK + US Market
  • Efficient light distribution
  • System PPF@1000W: 2016μmol/s
  • System PPF@1150W: 2339μmol/s

DIMLUX PRO 1000W

277-347V SMART EXCEEDCONN

  • 277V
  • EU + UK + US Market
  • Efficient light distribution
  • System PPF@1000W: 2016μmol/s
  • System PPF@1150W: 2339μmol/s



EASY REMOVABLE
ULTRA OPTICS REFLECTOR

Because the easier it gets the better and quicker it is especially when the reflector will be changed at high heights for replacement or cleaning. When growing in summer many greenhouse growers want to remove the reflector to prevent the reflector from deterioration and to decrease the amount of shadow on their plants.

AN ULTIMATE RANGE OF REFLECTORS TO MEET EVERYONE’S NEEDS



The main goal in designing the Ultra Optics Reflector was to achieve the highest efficiency (light output) possible. It’s designed according to the SBCS (Single Bounce Clear Sight) principle which

Ultra Optics Hybrid 96

The Hybrid reflector ensures a deep penetration into the plants, while having a larger overlap with other fixtures for better uniformity. The area it illuminates has an aspect ratio of 1.3:1. This reflector is the ideal choice for many scenarios because it combines the best qualities of the Deep and Wide reflectors.

Ultra Optics Wide 98

The Wide reflector illuminates a much wider area, which allows for a very short distance between the plants and the reflector. Because of the wider spread, the distance between the crop and reflector for the 1000W fixture is about the same as a regular 600W system. The area it illuminates has an aspect ratio of 2:1, a rectangle.

Ultra Optics Deep 98

The Deep reflector allows the light to penetrate very deep into the canopy. Because the Deep reflector directs more light downwards and less to the sides, losses due to walls and walking paths are minimized. The area it illuminates has an aspect ratio of 1:1, square.

4 DIGIT DISPLAY WITH A DIM SWITCH AND BOOST

Status and alarms will be displayed on this display. The Dimlux Pro Series can be remote controlled and controlled with the dim switch and with a 1000W bulb and in boost it can go up to 1150W.

CLOSED &
VERTICAL BALLAST

The Dimlux Pro Series has a closed ballast instead of an open ballast. This to prevent moisture getting into the ballast. The ballast is mounted vertically to decrease the amount of light which is intercepted by the fixture. The Dimlux Pro Series has the least light interception during a full day light cycle.

SMART BALLAST

The ballast is software upgradable and ready for the new digital controller platform

GEO MEMBRANE

This to equalize the pressure inside and outside the ballast, this is to prevent moisture getting into the ballast when cooling off.

SPECIFICATIONS PRO SERIES

Pro Series 1000W

347-400V

208-240V

208-277V

277-347V

347-400V

Exceedconn

Smart IEC

Smart Exceedconn

Smart Exceedconn

Smart Exceedconn

Article No.

2-733

2-734

2-735

2-736

2-737

Voltage:

400V

230V

277V

277V

400V

Input power @100%:

1032W

1035W

1032W

1032W

1032W

Input current @100%:

2.58A

4.5A

4.5A

3.7A

2.58A

Input power @boost

1187W

1242W

1242W

1187W

1187W

Input current @boost:

2.97A

5.4A

5.4A

4.25A

2.97A

Input frequency:

50/60 Hz

50/60 Hz

50/60 Hz

50/60 Hz

50/60 Hz

Power factor:

>0.95

>0.95

>0.95

>0.95

>0.95

System PPF@1000W:

2016μmol/s

2016μmol/s

2016μmol/s

2016μmol/s

2016μmol/s

System PPE@1000W:

1.95µmol/J

1.95µmol/J

1.95µmol/J

1.95µmol/J

1.95µmol/J

System PPF@1150W:

2339μmol/s

2339μmol/s

2339μmol/s

2339μmol/s

2339μmol/s

System PPE@1150W:

1.97µmol/J

1.96µmol/J

1.97µmol/J

1.97µmol/J

1.97µmol/J

Ultra High Frequency (UHF):

Yes

Yes

Yes

Yes

Yes

Controller:

By WiFi – Maxi controller

By WiFi – Maxi controller

By WiFi – Maxi controller

By WiFi – Maxi controller

By WiFi – Maxi controller

Measurements:

538×248×115mm

538×248×115mm

538×248×115mm

538×248×115mm

538×248×115mm

21.18x9.76x4.52inch

21.18x9.76x4.52inch

21.18x9.76x4.52inch

21.18x9.76x4.52inch

21.18x9.76x4.52inch

Weight:

4.1kg

4.1kg

4.1kg

4.1kg

4.1kg

Power cord:

2mt, 5mt, 10mt EP030 open leads

4mt IEC EU Plug

2mt, 5mt, 10mt EP030 open leads

2mt, 5mt, 10mt EP030 open leads

2mt, 5mt, 10mt EP030 open leads

4mt IEC UK Plug

4mt EPO30 240V USA Plug

4mt EP030 L7-15 USA plug

5mt IEC 240V USA Plug

4mt EP030 L7-15 USA plug
